Core Specifications
-
Wire Diameter: 0.1mm – 20mm
-
Outer Diameter: 1mm – 80mm
-
Free Length: 2mm – 400mm
-
Leg Length: 5mm – 300mm
-
Material: Stainless Steel (304, 316), Carbon Steel (SWC, SWP), Alloy Steel (Chrome Vanadium, Silicon Manganese), Brass, Bronze
-
End Types: Straight Legs, Hooked Legs, Offset Legs, Custom Leg Configurations
-
Torque Range: 0.01N·m – 1,000N·m
-
Surface Treatment: Zinc Plating, Nickel Plating, Black Oxide, Passivation, Electroplating
-
Standards: ISO, DIN 2089, ASTM A228, JIS B2704
Applications
Our torsion springs are designed to meet the rotational force needs of various industries, such as:
-
Automotive: Door hinges, seat belts, window regulators, ignition switches
-
Hardware: Clips, pliers, scissors, door locks, garage door mechanisms
-
Electronics: Printers, scanners, cameras, remote controls
- Medical Devices: Surgical forceps, rehabilitation equipment, diagnostic tools
- Industrial Equipment: Valves, levers, switches, conveyor systems
Types of Torsion Springs We Manufacture
Single (Helical) Torsion Springs
One coil body with two legs; the standard choice for hinges, latches and levers.
→See our
single(helical) torsion springDouble / Dual-Coil Torsion Springs
Two coil bodies joined for higher torque in a compact width.
→See our
double/dual-coil torsion springStainless Steel Torsion Springs
304 / 316 for corrosion resistance in medical, marine and outdoor use.
→See our
Stainless Steel Torsion SpringAutomotive Torsion Springs
IATF 16949 production for hinges, seat belts, window regulators and switches.
→See our
Automotive Torsion SpringsBattery Contact Torsion Springs
Small-wire torsion contacts for electronics, remotes and battery compartments.
→See our
Battery Contact Torsion SpringsBow-Shaped Torsion Springs
Custom bow-form legs for specialized clamping and return-force applications.
→See our
Bow-Shaped Torsion Springs
GL Springs Advantages
-
Stable Torque Performance: Advanced testing equipment ensures torque tolerance ≤ ±5%
-
Custom Design Flexibility: Support for special leg shapes, torque requirements, and material grades
-
Long Service Life: Strict material selection and heat treatment process reduce fatigue failure
-
Fast Delivery: 7-day sampling for custom orders, 15-day mass production lead time
